Adams Rite 8611-36" 628 Narrow Stile Concealed Vertical Rod Exit Device

Features: Patented top latching mechanism interlocks door to frame

• Top and bottom adjustable steel rods
• Pushbar anodized or clad not plated in a variety of finishes
• Easy to install Clean, unobtrusive design
• Strong durable construction for a high level of security
• ANSI/BHMA: Grade 1
• Handing: Device is non-handed. Lever entry trim is field reversible.
• Pushbar length: 36"  Standard width bars can be field cut to the next smallest opening width.
• Projection: 2-5/8" when fully projected. 1-5/8" when dogged.
• Door thickness: 1-3/4" standard up to 2-1/4". Device requires modification when used with cylinder in doors over 1-3/4".
• Stile Wall: Doors with stile walls other than 1/8" require modification.
• Stile Width: Minimum 2" stile. Fits narrow, medium and wide stile aluminum doors.
• Bar Height: Adjustable from 30" to 44"
• Door Height: Standard unit adjustable for doors up to 66" above the selected bar height.
• Materials: Pushbar made of extruded aluminum
• Dogging: Standard dogging with hex key or optional cylinder dogging
• Fasteners: Standard self-tapping screws.
• Strike: Made of hardened steel. Supplied.
• Warranty: Five year limited
• Bolt & Strikes: The patented top latching mechanism utilizes a rotating top bolt which dead latches around the header strike, interlocking the door to the frame.
• Supplied with standard header strike.
• The hexagonal, hardened steel bottom bolt works in harmony with the top bolt.
• Clear anodized stainless steel
